KIOTI CK4020 Compact Tractor

⚙️ The Kioti CK4020 is a 40 hp compact tractor designed for versatility and performance. Available in both Hydrostatic (HST) and Manual (Gear) transmission options, it offers robust capabilities for a variety of tasks.

Engine & Performance

• Engine Model: 3H-TM4A
• Gross Power: 39.6 hp (29.5 kW)
• Rated Speed: 2,600 rpm
• Fuel Type: Diesel, Tier 4 compliant
• Displacement: 1.826 L (111.4 cu in)
• Fuel Tank Capacity: 9.0 gal (34 L)

Transmission & Drive

• Transmission Options:
• Manual: 9F/3R Synchro Shuttle
• Hydrostatic (HST): Twin-pedal, 3-range
• Drive: 4WD standard
• Clutch (Manual): Dry single-plate

PTO (Power Take-Off)

• Rear PTO: Independent, 540 rpm
• Mid PTO: Optional, 2,000 rpm
• PTO Engagement: Mechanical lever (Manual) / Electro-hydraulic (HST)

Brakes, Steering & Differential

• Brakes: Wet multi-disc
• Steering: Hydrostatic power steering
• Differential Lock: Rear, standard

Hydraulics & Hitch

• Hydraulic Pump Capacity: 11.7 gpm (44.4 L/min)
• 3-Point Hitch: Category I with position control
• Lift Capacity (24" behind hitch): 1,631 lbs (739 kg)

Dimensions & Weight

• Length (with 3-point hitch): 120.9 in (3,070 mm)
• Width: 54.5 in (1,385 mm)
• Height (ROPS): 92.9 in (2,520 mm)
• Wheelbase: 65.7 in (1,670 mm)
• Ground Clearance: 13.4 in (340 mm)
• Turning Radius (with brake): 107.5 in (2,730 mm)
• Weight (ROPS): 2,734 lbs (1,240 kg)

Tire Options

• Agricultural: Front 15–19.5 / Rear 27×8.5–15
• Industrial: Front 25×8.5–14 / Rear 15–19.5
• Turf: Front 23×8.5–12 / Rear 33×12.5–16.5

Best Uses

The Kioti CK4020 is ideal for:

• Small to mid-sized farms: Tilling, plowing, and hauling
• Landscaping and property maintenance: Mowing, grading, and snow removal
• Loader and implement work: Handling spreaders, box blades, and post hole diggers
• General utility tasks: Versatile power for various applications
